Bellagio Conquest

SKU: Bellagio Conquest Category:

Description

A massive floorstanding structure of 100 kilos with a 270 mm platter spindle and fully adjustable high torque DC motor

THIRTEEN DIFFERENT CURVED PLINTHS
Conquest is the only turntable to feature thirteen different curved plinths achieving maximum stiffness and indeformability and allowing the best resonance feedback control: plinths are interfaced with titanium spacers of different thickness joined together with custom machined solid blocks of aluminium and extra-large feet.

THE LONGEST PLATTER SPINDLE EVER
A 270 mm spindle, the longest made for a turntable, ever!  Made of the hardest carbon steel, hardened with boiling oil process, rectified and polished to guarantee the best working fluidity. Polished bronze is used for the bearing, engineered to get a 1/100 millimeter matching tolerance with the spindle: the amazing length of the system is capable of the smoothest platter rotation available and forces distribution control along the spindle’s axis to deliver fantastic audio performances.

REMOTE CONTROL
Conquest Series is the only family of high-end turntables coming with remote to let you always be in control of all functions: ON/OFF, speed change, speed control and power control.

POWER CONTROL AND HOURGLASS MOTOR PULLEY
To power our best turntable we chose our best technology, a PWM generator – Pulse Width Modulation: PWM power drive generates AC-DC-AC enabling the best coupling of the two AC semi-wave annulling motor resistance and vibrations and still maintaining the highest torque.

The new anti-resonating dampened hourglass shaped motor pulley stops transmission vibrations; it’s precisely machined and polished to achieve perfectly smooth surfaces and guarantee low rotational noise and great durability.

CONTROL THE POWER OF YOUR MUSIC
Conquest Series is the only family of high-end turntables to feature a unique “Power Control System”: controlling the motor’s torque is to control your music by finely adjusting the turntable’s “character”.

Selecting lower torque is indicated when playing ancient or chamber string music, where details strongly matter; while the maximum torque should be used for rock or symphonic music to enabling maximum dynamic.

Power Control System is conveniently performed by remote control to let you choose the best sound directly from your listening point.

Additional information

Brand

,

Wow & Flutter: 0,05%
Rumble: -85dB
Speed: 33-1/3 and 45 rpm +/-0,1%
Speed changing: electronic fully remotable with fine pitch control
Motor control: fine tuned High Torque
Motor: 12V High Torque synchronous external power supply
Dimensions: 530mm W | 1250mm H | 500mm D
Weight: 100kg

Power
Mains supply: 100/115/230V, 50/60Hz, depending on market destination and not convertible
Power consumption: 20W max
Transmission: 70 shores elasticity rectified black polyvinyl belt & anti resonating hourglass pulley
Platter: Double Disc Sustarin® 110mm height
Platter spindle: 270mm rectified extra hardened C40 clamping the platter
Platter bearing: 4.2mm Tempered Ceramic ball bearing with adjustable bronze seat in finely Polished bronze bearing case
Platter rocker arm: 550mm rocker arm with elliptical counterweight

Upgrades
External AC filter: Lucca Power Distributor
Other: Gold Note Lucca power chord
