CONSTRUCTION DETAILS Resonance optimised chassis’s shape, belt driven with optical, full automatic speed control
SPEED RANGES 33 ⅓ rpm, 45 rpm, 78 rpm
DRIVE UNIT Decoupled DC motor in a massive metal-housing.
This turntable can be connected to 230 V or 110 V AC (50 Hz and 60 Hz).
BEARING Inverted and polished ceramic bearing shaft, polished sinter bronze insert, including patented CMB bearing technology
PLATTER VA stainless steel sub-platter, Delrin or acrylic GS-PMMA platter, precision CNC machined surface
SPEED ACCURACY (MEASURED) less than ± 0.05 %
DEVIANCE OF THE SET VALUE ± 0.01 %
POWER CONSUMPTION Max. consumption: 9.3 Watt
Consumption in operation: 2.5 Watt
Standby mode: 2.5 Watt
Off mode: 0.0 Watt
TOTAL WEIGHT Approx. 23 kg (without tonearm and power supply)
DIMENSIONS (W/D/H in inches) Approx. 16.85 x 15.35 x 8.19 (without tonearm)
DIMENSIONS (W/D/H in mm) Approx. 428 x 390 x 208 (without tonearm)
