Description
The addition of Ortofon’s unique Replicant 100 stylus and reduced tip mass ensures open and detailed sound reproduction for a purely exquisite listening experience.
Electrum coils, consisting of a gold and silver alloy, provides uncolored and precise transmission of armature movements while the slightly modified damping system makes it possible to reduce VTF and achieves a higher level of linearity.
High purity 6-nines copper wiring ensures impeccable signal transmission and preservation of the finest of microdynamic detail.
Technical data
tput voltage at 1000 Hz, 5cm/sec. – 0.2 mV
Channel balance at 1 kHz < 1 dB Channel separation at 1 kHz > 25 dB
Channel separation at 15 kHz > 20 dB
Frequency response – 20-20.000 Hz + 1,5/- 0 dB
Tracking ability at 315Hz at recommended tracking force *) > 70 µm
Compliance, dynamic, lateral – 8 µm/mN
Stylus type – Nude Ortofon Replicant 100
Stylus tip radius – r/R 5/100 µm
Tracking force range – 2.5-3.5 g (25-35 mN)
Tracking force, recommended – 3.0 g (30 mN)
Tracking angle – 20°
*) Typical value
Internal impedance, DC resistance – 6 ohm
Recommended load impedance > 100 ohm
Coilwire material – Electrum
Cartridge colour – Black
Cartridge weight – 13 g
