The Ortofon TA-100 tonearm combines familiar looks and construction with a modern design where the emphasis is placed on rigorous quality and maximization of the performance. It is a static balanced gimbal type arm, which makes it easy to use and adjust for optimal VTF settings.
Equipped with a standard headshell connector, TA-100 can easily be adjusted in accordance with the included mounting template.
The TA-100 has a standard 5-pin DIN connector for tonearm cable.
The tonearm geometry allows for a Baerwald alignment (also the IEC recommendations).
The TA-100 can ideally be combined with all SPU cartridges. The heavier counterweight is however important for the SPU-users and can be acquired separately.
TA-100 tonearm Technical data
Effective mass (without headshell) – 5g
Effective length (distance between the stylus and pivot point) – 231mm
Length (distance between the pivot point and turntable center) – 213mm
Offset angle – 23.9 degrees
Overhang – 18mm
Tracking force adjusting range ( direct reading) – 0 to 3g
Tracking force adjusting range (with extra mass ring mounted) – 0 to 4g
Height adjustment range – 35mm to 55mm
Diameter of the armbase mounting hole – 19mm to 20mm
Diameter of center shaft – 18mm
Optional counterweight for heavier cartridges between 26 and 38 grams is available
Standard counterweight for cartridges between 18 and 28 grams included
One set of cables 6NX-TSW-1010 included
Headshell LH-2000E included
