SPU Synergy A

Category:

Description

The SPU Synergy A modernizes the classic SPU design with a number of optimizations designed for optimum compatibility and sonic purity.

The SPU Synergy features a wood-based housing and has a revised generator system which allows for a maximum output of 500µV, relaxing the requirement for high gain transformer or active preamplification systems.

While still making use of a highly polished Nude Elliptical stylus, the stylus tip mass has been reduced significantly, resulting in reduced VTF and higher tracking ability.

The SPU Synergy A provides all of the sonic capabilities of the legendary SPU Synergy GM, but in a short-shell format for use with a variety of tonearms which require a cartridge with a shorter overhang.

Additional information

Brand

SPU Synergy A Technical data

Output voltage at 1000 Hz, 5cm/sec. – 0,5 mV
Channel balance at 1 kHz – < 1,5 dB Channel separation at 1 kHz – > 23 dB
Channel separation at 15 kHz – > 15 dB
Frequency range at – 3dB – 20-30.000 Hz
Frequency response – 20-20.000 Hz ± 2 dB
Tracking ability at 315Hz at recommended tracking force – 70 µm
Compliance, dynamic, lateral – 8 µm/mN
Stylus type – Nude elliptical
Stylus tip radius – r/R 8/18 µm

Tracking force range – 2,5-3,5 g (25-35 mN)
Tracking force, recommended – 3,0 g (30 mN)
Tracking angle – 20°
Internal impedance, DC resistance – 2 Ohm
Recommended load impedance – 10 – 50 Ohm
Cartridge body material – Bakelite
Coilwire material – High Purity Copper (OFC)
Cartridge colour – Shiny Black
Cartridge weight – 29 g
