an improved engine, which provides an increased output of 5.5mV and an optimized sound reproduction and a high level of sonic accuracy
– Nude Elliptical diamond and split pole pins with a copper wire
2M Blue adds more dynamics and resolution, sounds more open and reproduces more details than 2M Red
| Brand |
|---|
Output voltage at 1000 Hz, 5cm/sec. – 5,5 mV
Channel balance at 1 kHz – 1,5 dB
Channel separation at 1 kHz – 25 dB
Channel separation at 15 kHz – 15 dB
Frequency range at – 3dB – 20-25.000 Hz
Frequency response – 20-20.000 Hz + 2 / – 1 dB
Tracking ability at 315Hz at recommended tracking force – 80 µm
Compliance, dynamic, lateral – 20 µm/mN
Stylus type – Nude Elliptical
Stylus tip radius – r/R 8/18 µm
Tracking force range – 1,6-2,0g (16-20 mN)
Tracking force, recommended – 1,8 g (18 mN)
Tracking angle – 20°
Internal impedance, DC resistance – 1,3 kOhm
Internal inductance – 700 mH
Recommended load resistance – 47 kOhm
Recommended load capacitance – 150-300 pF
Cartridge colour, body/stylus – Black/Blue
Cartridge weight – 7,2 g
Replacement stylus unit – 2M Blue (interchangeable with 2M Red and 2M Silver)
